ADMAG AXG is a high-quality and highly reliable magnetic flowmeter, enhanced by Yokogawa’s proprietary dual frequency excitation method.
Certified to SIL2 complied with functional safety standard IEC 61508, it can be used in safety instrumented systems up to SIL2 in simplex configuration and SIL3 in a redundant configuration. In addition, the AXG is certified in the Water industry with the NSF61 approval for drinking water.
Product Details
Description
The ADMAG Total Insight (TI) AXG® is an electromagnetic flow meter featuring enhanced settings for customized setups, pre-defined trend views, and multiple configuration sets for fast changeover through micro SD card. The ADMAG TI AXG® comes standard with built-in verification, reducing total cost of ownership.
Some of the highlights of the ADMAG TI AXG® include:
|
|
AXG4A |
AXW4A |
AXG1A |
|
microSD Data Storage |
Yes |
Yes |
Yes |
|
Build-In Verification |
Yes |
Yes |
Yes |
|
Application Diagnostic |
Yes |
N/A |
Yes |
|
Current, Pulse, |
Current 2ch |
Current 1ch |
Current 2ch |
|
Status Input |
1ch |
1ch |
2ch |
|
Current Input |
1ch |
N/A |
1ch |
|
Intrinsically Safe Output |
1ch (Alternative) |
N/A |
N/A |
|
Explosion Proof |
FM, ATEX, IECEx |
N/A |
N/A |
|
Yokogawa Backward Compatibility |
N/A |
N/A |
Yes |
|
Third-Party Flow Tubes Compatibility |
N/A |
N/A |
Yes |
* Please refer to General Specifications in detail.
|
|
AXG Flow Sensor |
AXW Flow Sensor |
|
Diameter |
2.5 to 500mm |
25 to 1800mm |
|
Liner Variation |
Ceramic, PFA |
PTFE, Polyurethane rubber, |
|
Accuracy |
± 0.3% of rate |
± 0.35% of rate |
|
High Accuracy |
± 0.15% of rate |
N/A |
* Please refer to General Specifications in detail.
