| Feature | Technical Data |
| Nominal Diameter | DN 25 to 3000 (1" to 120") |
| Max. Measurement Error | Standard: ±0.5% |
| Liner Materials | Polyurethane, Hard Rubber, PTFE |
| Connectivity | PROFINET, EtherNet/IP, Modbus, HART, WLAN |
| Approvals | NSF 61, WRAS, KTW-BWGL, ATEX, SIL 2/3 |
| Maintenance | Heartbeat Technology for in-situ verification |
Cost-Effective Installation: The 0 x DN full-bore option means no straight pipe runs are required before or after the meter. This significantly reduces installation costs and allows for extremely compact plant designs.
Drinking Water Certified: Fully compliant with international standards like NSF 61 and WRAS, ensuring safe usage in municipal water supply networks.
Digital Diagnostics (Heartbeat): No more costly process interruptions. Heartbeat Technology provides continuous self-diagnostics and traceable verification according to ISO 9001.
Smart Operation: Built-in WLAN and Web Server allow your team to configure and troubleshoot via any mobile device without opening the housing.
The Challenge: A city water plant needed to install a DN 1200 flowmeter in a tight underground chamber with multiple pipe bends. The Solution: We provided the Promag W 300 with 0 x DN option. The Result: The plant saved over $20,000 in structural modification costs, as no straight piping was needed, maintaining a constant ±0.5% accuracy despite the complex layout.
