26GHz K-band radar, non-contact measurement, unaffected by medium, temperature, steam and gas phase changes, stable measurement
Designed for extreme working conditions, resistant to high temperature (max 450℃) and high pressure (max 160bar), suitable for harsh scenarios such as petroleum and chemical industry
Dual ceramic coupling and hermetic lead design, extremely high safety, capable of coping with extremely complex working conditions
Complies with IEC 61508 standard, a single instrument meets SIL2, and reaches SIL3 under homogeneous redundancy conditions, with excellent safety performance
HistoROM integrated data storage unit enables rapid commissioning, maintenance and fault diagnosis, improving maintenance efficiency
Multi-echo tracking calculation ensures accurate measurement (accuracy ±2mm) even with obstacles in the tank
Equipped with Heartbeat Technology to ensure efficient and safe operation of the plant throughout its life cycle and reduce operation and maintenance costs
Intuitive menu-guided operation, operable on-site or through the control system, seamlessly integrated into various systems
Passes internationally authoritative SIL and WHG test certifications, no additional testing required, saving time and economic costs
Supports Bluetooth® wireless connection, remote access and commissioning via SmartBlue app
Diverse wetted materials (316L, AlloyC alloy, PTFE, ceramic) to adapt to different corrosion scenarios
Specifications
Measuring Principle：Radar Level Transmitter
Frequency：K-band (26 GHz)
Measuring Accuracy：±2 mm (0.08 in)
Maximum Measuring Distance：Standard: 40 m (131 ft); With optional advanced diagnostic function: 70 m (230 ft)
Ambient Temperature：-50...+80°C (-58...+176 °F)
Process Temperature：Heated version: -196...+280°C (-321...+536°F); High-temperature version: -196...+450°C (-321...+842°F)
Process Pressure (absolute)：Vacuum...160 bar (2320 psi)
Wetted Parts：316L, AlloyC Alloy, PTFE, Ceramic
Process Connections：
- Thread: MNPT 1 1/2, R 1 1/2
- Flange: DN50...150, ASME 2"...6", JIS 10K, 63K
- Hygienic Process Connections: Tri-Clamp ISO2852
Power/Communication：2-wire (HART, PROFIBUS PA, FOUNDATION Fieldbus); 4-wire (HART)
Communication：4...20 mA HART, PROFIBUS PA, FOUNDATION Fieldbus
